Dry needling


Description

Dry Needling.jpg
Trigger-point dry needling is an invasive procedure where an acupuncture needle is inserted into the skin and muscle. It is aimed at myofascial trigger points which are hyperirritable spots in skeletal muscle that are associated with a hypersensitive palpable nodule in a taut band.[1] Trigger point dry needling can be carried out at superficial or deep tissue level.
  •  Superficial dry-needling [2]

This was developed by Peter Baldry. He recommended the insertion of needles to 5-10mm over a MTrP for 30 secs. Palpation of the MTrP then determined the level of response and whether needle stimulation was sufficient to alleviate MTrP pain. If not the need was re-inserted.

  •  Trigger point model
Trigger point pain.jpg

The trigger point model is a dry needling technique that specifically targets myofascial trigger points. They are thought to be due to an excessive release of acetylcholine from selected motor endplates. They can be divided into Active and Latent myofascial trigger points.

  • Active trigger points can spontaneously trigger local or referred pain. They cause muscle weakness, restricted ROM and autonomic phenomena.
  • Latent trigger points do not cause pain unless they are stimulated. They may alter muscle activation patterns and contribute to restricted ROM.
  • Therefore both active and latent trigger points cause allodynia at the trigger point site and hyperalgesia away from the trigger point following applied pressure.[3]
  • The formation of trigger points is caused by the creation of a taut band within the muscle. This band is caused by excessive acetylcholine release from the motor endplate combined with inhibition of acetylcholine esterase and upregulation of nicotinic acetylcholine receptors.

Initially taut bands are produced as a normal protective, physiological measure in the presence of actual or potential muscle damage. They are thought to occur in response to unaccustomed eccentric or concentric loading, sustained postures and repetitive low load stress. However when sustained they contribute to sustained pain.

  • Pain caused by trigger points is due to hypoxia and decreased bloodflow within the trigger point. This leads to a decreased pH which activates the muscle nociceptors to restore homeostasis. This causes peripheral sensitization.
  • Trigger points are also involved in central sensitization. The mechanism remains unclear but trigger points maintain nocioceptive input into the dorsal horn and therefore contribute to central sensitization.
[4]

Suggested mechanisms of effect:

Stimulation of a local twitch response (LTR)  [5]

Dry-needling of these myofascial trigger points via mechanical stimulation causes an analgesic effect. This mechanical stimulation causes a local twitch response (LTR). An LTR is an involuntary spinal cord reflex contraction of the muscle fbers in a taut band. Triggering an LTR has been shown to reduce the concentration of nociceptive substances in the chemical environment near myofascial trigger points.[6] [7]

Muscle regeneration

The needle may cause a small focal lesion which triggers satellite cell migration to the area which repair or replace damaged myofibers. This occurs 7-10 days after dry needling. It is unclear whether continued dry needling within this period may disrupt this process.

A localised stretch to the cytoskeletal structures

This stretch may allow sarcomeres to resume their resting length.

Electrical polarization of muscle and connective tissue

The mechanical pressure causes collagen fibers to intrinsically electrically polarize which triggers tissue remodelling.[8]

Indication

  • Identification of myofascial trigger points in the muscle through palpation
  • Deep dry needling reproduces the patient's pattern of pain
  • Identification of 'Jump' and 'Shout' sign on palpation on MTrP
  • The minimum criteria for diagnosis of myofascial trigger points are:[9]

-Spot tenderness in a palpable band of skeletal musle

- Subject recognition of pain with palpation

- Clinical presentation

Contradindications

Absolute contraindications[10]

DN therapy should be avoided in patients under the following circumstances[11][12]:

  1. In a patient with needle fobia.
  2. Patient unwillng - fear, patient belief.
  3. Unable to give consent - communication, cognitive, age-related factors.
  4. Medical emergency or acute medical condition.
  5. Over an area or limb with lymphedema as this may increase the risk of infection/cellulitis and the difficulty of fighting the infection if one should occur.
  6. Inappropriate for any other reason.

Relative Contraindications[10]

  1. Abnormal bleeding tendency
  2. Compromised immune system
  3. Vascular disease
  4. Diabetes
  5. Pregnancy
  6. Children
  7. Frail patients
  8. Patients with epilepsy
  9. Phychological status
  10. Patient allergies
  11. Patient medication
  12. Unsuitable patient for any reason

Procedure post treatment:

  • Assess ROM for restriction and pain
  • Give patient a stretching programme
  • Identify activities that may reactivate MTrP

Key evidence

The effectiveness of this treatment depends greatly on the skill of the therapist to accurately palpate mysofascial trigger points as well as kinaesthetic awareness of the anatomical structures.

- A cochrane review (2005) of RCTs concluded that trigger point dry needling may be beneficial for low back pain when used in combination with other treatments. However further higher quality studies are needed to confirm this.[13]

- It is suggested that dry-needling reduces/removes nociceptive input from trigger points, normalize synaptic efficacy and reduce peripheral and central sensitization.

- Dry-needling can restore muscle activation and strength as well as ROM.

- Dry-needling decreases pain in patients with Chronic low back pain and in patients with hemiparetic upper limb post CVA.[14]

- A systematic review of 23 trials considering needling therapies for myofascial trigger point pain concluded that direct dry-needling (where MTrPs were directly targetted) was as benificial as wet needling.[9] There is no clear evidence that it is beneficial above placebo. More studies of higher quality with a reproducible diagnostic criteria and a valid placebo are needed to draw firm conclusions on this.

- A systematic review and meta analysis with level 1a evidence suggests that:[15]

  • Very low–quality to moderate quality evidence suggests that dry needling performed by physical therapists is more effective than no treatment, sham dry needling, and other treatments for reducing pain and improving pressure pain threshold in patients presenting with musculoskeletal pain in the immediate to 12-week follow-up period.
  • Low-quality evidence suggests superior outcomes with dry needling for functional outcomes when compared to no treatment or sham needling.
  • No difference in functional outcomes exists when compared to other physical therapy treatments.
  • Evidence of long-term benefit of dry needling is currently lacking.

References

  1. Dommerholt, J., Del Morel, O. and Grobli, C. Trigger point dry needling. The journal of manual and manipulative therapy 2006;14(4), 70-87
  2. Baldry, P. Superficial versus deep dry-needling. Acupuncture in medicine 2002;20(2-3), 78-81
  3. Dommerholt, J. Dry-needling-peripheral and central considerations. Journal of manual and manipulative therapy. 2011;19(4), 223-238
  4. Tim Trevail. Dry Needling: Trapezius. Available from: https://www.youtube.com/watch?v=MB4mVDqU1y0
  5. Ga H, Choi JH, Park CH, Yoon HJ. Dry needling of trigger points with and without paraspinal needling in myofascial pain syndromes in elderly patients. J Altern Complement Med. 2007; 13: 617– 624.
  6. Chen JT, Chung KC, Hou CR, Kuan TS, Chen SM, Hong CZ. Inhibitory effect of dry needling on the spontaneous electrical activity recorded from myofascial trigger spots of rabbit skeletal muscle. Am J Phys Med Rehabil 2001; 80: 729–35.
  7. Ga H, Choi JH, Park CH, Yoon HJ. Dry needling of trigger points with and without paraspinal needling in myofascial pain syndromes in elderly patients. J Altern Complement Med. 2007; 13: 617– 624.
  8. Chen JT, Chung KC, Hou CR, Kuan TS, Chen SM, Hong CZ. Inhibitory effect of dry needling on the spontaneous electrical activity recorded from myofascial trigger spots of rabbit skeletal muscle. Am J Phys Med Rehabil 2001; 80: 729–35.
  9. 9.0 9.1 Cummings, T.M. and White, A.R. Needle therapies in the management of myofascial trigger point pain: a systematic review. Achive of physical medicine and rehabilitation 2011;82, 986-992
  10. 10.0 10.1 Dommerholt J., Fernandez-de-las-Penas C. Trigger Point Dry Needling. An Evidenced and Clinical-Based Approach. Edinburgh: Churchill Livingstone-Elsevier, 2013
  11. Australian Society of Acupunture Physioterapists Inc. Guidelines for safe acupuncture and dry needling practice, 2007.
  12. White, A., Cummings M., Filshie, J. Evidence of safety of acupuncture. An introduction to Western medical acupuncture. Edinburgh: Churchill Livingstone, 2008.
  13. Furlan AD, van Tulder MW, Cherkin D, Tsukayama H, Lao L, Koes BW, Berman BM. Acupuncture and dry-needling for low back pain. Cochrane Database of Systematic Reviews 2005, Issue 1.
  14. Ana Mendigutia-Gómez, PT, PhD, Carolina Martín-Hernández, PT, Jaime Salom-Moreno, PT, PhD, César Fernández-de-las-Peñas, PT, PhD. Effect of Dry Needling on Spasticity, Shoulder Range of Motion, and Pressure Pain Sensitivity in Patients With Stroke: A Crossover Study. DOI: http://dx.doi.org/10.1016/j.jmpt.2016.04.006
  15. Gattie E, Cleland JA, Snodgrass S. The effectiveness of trigger point dry needling for musculoskeletal conditions by physical therapists: a systematic review and meta-analysis. journal of orthopaedic & sports physical therapy. 2017 Mar;47(3):133-49.
