Introduction

Auscultation is the term for listening to the internal sounds of the body, usually using a stethoscope. Auscultation is performed for the purposes of examining the circulatory system and respiratory system (heart sounds and breath sounds), as well as the gastrointestinal system (bowel sounds).  It is an integral part of physical examination of a patient and is routinely used to provide strong evidence in including or excluding different pathological conditions that are manifested clinically in the patient.

The stethoscope comprises a bell and a diaphragm. The bell is most effective at transmitting lower frequency sounds, while the diaphragm is most effective at transmitting higher frequency sounds[1].  In other words, the bell is designed to hear low pitched sounds and the diaphragm is designed to hear high pitched sounds. They are connected via rubber tubing to the ear pieces. These should be worn facing forward as the ear canals run anteriorly.

Techniques

To optimise the effectiveness of auscultation the surroundings should be:[2]

  1. Quiet - the ambient noise might interfere the heart and lung sounds.
  2. Warm - so that the patient feels comfortable while the upper part of the body is being exposed. Also, it is to avoid shivering that may add the noise.
  3. Appropriate lighting - to allow good coordination between visual and auscultatory findings.

Respiratory Examination

Ideally, for Respiratory examination, the patient would be sitting.

Auscultate from side to side and top to bottom. Omit the areas covered by the scapulae.

  1. Usually the APEX of the lungs bilaterally (2cm superior to medial 1/3 of clavicle)
  2. Superior Lobes anterior (2nd intercostal space mid clavicular line) and posterior (Between C7 & T3)
  3. Inferior Lobes bilaterally anterior (6th intercostal space, mid-axiallary line) and posteriorly (between T3 & T10)
  4. Middle lobe right anterior only (4th intercostal space mid-clavicular line)

Compare one side to the other looking for asymmetry and note the location and quality of the sounds you hear.

Technique

  • Ask the patient to disrobe, as this will allow the stethoscope to be placed directly on the chest.
  • Make sure the patient is sits upright in a relaxed position, where this is possible.
  • You should then instruct the patient to breathe a little deeper than normal through the mouth.
  • The bell/diaphragm of the stethoscope is then placed against the chest wall.
  • Auscultation of the lungs should be systematic, including all lobes of the anterior, lateral and posterior chest.
  • The examiner should begin at the top, compare side with side and work towards the lung bases.
  • The examiner should listen to at least one ventilatory cycle at each position of the chest wall.
  • The examiner should identify four characteristics of breath sounds: pitch, amplitude, distinctive characteristics and duration of the inspiratory sound compared with the expiratory sound.
[3]
[4]

Cardiac examination

It should be noted that auscultation comes after palpation, the patient is normally lying comfortably at 45 degrees angle with their chest region fully exposed.

There are four main regions of interest for auscultation, and a brief knowledge in human anatomy is crucial to pinpoint them.

The 4 pericardial areas are examined with diaphragm[5], including:

  1. Aortic region (between the 2nd and 3rd intercostal spaces at the right sternal border) (RUSB – right upper sternal border).
  2. Pulmonic region (between the 2nd and 3rd intercostal spaces at the left sternal border) (LUSB – left upper sternal border).
  3. Tricuspid region (between the 3rd, 4th, 5th, and 6th intercostal spaces at the left sternal border) (LLSB – left lower sternal border).
  4. Mitral region (near the apex of the heard between the 5th and 6th intercostal spaces in the mid-clavicular line) (apex of the heart).

The four pericardial areas relate to the heart sounds and can detect various abnormalities in the heart such as the valve stenosis or incompetence which are diagnostic for many diseases in the cardiovascular system. However, there are specific manoeuvres done for further investigation, and some of these would include[6]

Lung Sounds

Normal lung sounds

Vesicular -  are usually quiet, mostly inspiratory, with a distinctive pause before a quieter expiratory phase. They are soft and low pitched with a rustling quality during inspiration and are even softer during expiration. These are the most commonly auscultated breath sounds, normally heard over the most of the lung surface. They have an inspiration/expiratory ratio of 3 to 1 or I:E of 3:1.

Listen to vesicular sounds

Bronchovesicular - heard over the 1st and 2nd intercostal spaces and the interscapular area. The inspiratory and expiratory phases are roughly equal in length. They reflect a mixture of the pitch of the bronchial breath sounds heard near the trachea and the alveoli with the vesicular sound.

Bronchial - may be normally heard over the manubrium. Expiratory phase is greater than inspiratory. The expiratory pitch is high and intensity is loud. Hollow, tubular sounds that are lower pitched.

Tracheal - heard directly over the trachea. Inspiratory phase equals the expiratory phase. The sound is very loud and the pitch very high.

Abnormal lung sounds


Sounds:
Listen: Sounds like:
Caused by:
Crackles - Fine Crackles - Fine Brief, discontinuous, popping lung sounds that are high-pitched. Fine crackles are also similar to the sound of wood burning in a fireplace, or hook and loop fasteners being pulled apart or cellophane being crumpled. Crackles, previously termed rales, can be heard in both phases of respiration. Early inspiratory and expiratory crackles are the hallmark of chronic bronchitis. Late inspiratory crackles may mean pneumonia, CHF, or atelectasis. Small airways open during inspiration and collapse during expiration after collapsing due to loose secretions or lack of aeration during expiration (atelectasis)
Crackles - Coarse Crackles - Coarse Discontinuous, brief, popping lung sounds. Compared to fine crackles they are louder, lower in pitch and last longer. They have also been described as a bubbling sound. Typically inspiratory and particularly wet sounding Excessive fluid within the lungs
Wheeze Wheeze Adventitious lung sounds that are continuous with a musical quality. Wheezes can be high or low pitched. High pitched wheezes may have an auscultation sound similar to squeaking. Lower pitched wheezes have a snoring or moaning quality. The proportion of the respiratory cycle occupied by the wheeze roughly corresponds to the degree of airway obstruction. Forced airflow through abnormally narrowed airways with residual trapping of air
Rhonchi - Low pitched wheezes Rhonchi - Low Pitched Wheezes Low pitched wheezes (rhonchi) are continuous, both inspiratory and expiratory, low pitched adventitious lung sounds that are similar to wheezes. They often have a snoring, gurgling or rattle-like quality. Rhonchi occur in the bronchi. Sounds defined as rhonchi are heard in the chest wall where bronchi occur, not over any alveoli. Rhonchi usually clear after coughing.
Plural Rub Pleural Rubs Discontinuous or continuous, creaking or grating sounds. The sound has been described as similar to walking on fresh snow or a leather-on-leather type of sound. Coughing will not alter the sound. They are produced because two inflamed surfaces are sliding by one another, such as in pleurisy. Pleural surfaces are inflamed or roughened and rub against each other


Crackles

Listen to Crackles

Crackles (rales) are caused by excessive fluid (secretions) in the airways. It is caused by either an exudate or a transudate. Exudate is due to lung infection e.g pneumonia while transudate such as congestive heart failure[5]. A crackle occurs when a small airways pop’s open during inspiration after collapsing due to loos esecretions or lack of aeration during expiration (atelectasis)[7]. Crackles are much more common in inspiratory than in expiratory.

Crackles are high-pitched and discontinuous. They sound like hair being rubbed together[7]. There are three different types; fine, medium and coarse.

  • Fine are typically late inspiratory and coarse are usually early inspiratory
  • Fine crackles are high pitched, very brief and soft. It sounds like rolling a strand of hair between two fingers. Fine crackles could suggest an interstitial process; e.g pulmonary fibrosis, congestive heart failure.
  • Coarse crackles are louder, more low pitched and longer lasting. They indicate excessive fluid on the lungs which could be caused by aspiration, pulmonary oedema from chronic heart disease, chronic bronchitis, pneumonia[8].

Wheezes

Listen to Wheezes

Wheezes are an expiratory sound caused by forced airflow through collapsed airways. Due to the collapsed or abnormally narrow airway, the velocity of air in the lungs is elevated[9]. Wheezes are continuous high pitched hissing sounds. They are heard more frequently on expiration than on inspiration. If they are monophonic it us due to an obstruction in one airway only but if they are polyphonic than the cause is a more general obstruction of airways[10]. Where the wheeze occurs in the respiratory cycle depends on the obstructions location[11], if wheezing occurs in the expiratory phase of respiration it is usually connected to broncholiar disease[12]. If the wheezing is in the inspiratory phase, it is an indicator of stiff stenosis whose causes range from tumours to scarring. One of the main causes of wheezing is asthma[12] other causes could be pulmonary edema, interstitial lung disease and chronic bronchitis.

Pleural Rub
Pleural Rub produces a creaking or brushing sound. These occur when the pleural surfaces are inflamed and as a result rub against one another. They are heard during both inspiratory and expiratory phases of the lung cycle and can be both continuous and discontinuous. Pleural rub can suggest pleurisy, pneumothorax or pleural effusion.

Heart Sounds

Sites of Chest Auscultation

Blood flowing across the heart valves is laminar flow so that no sound is produced. The sounds heard on auscultation are the sound of the valve cusps snapping shut at the end of diastole (when the AV valves shut producing the 1st heart sound) and at the end of systole (when the Aortic Pulmonary valves shut producing the 2nd heart sound).

These sounds are conducted to the surface of the body and can be heard with the aid of a stethoscope. There are specific places on the anterior chest wall where the sound from each of the 4 valves can best be heard. These are not the surface markings of the valves but rather the points where the sounds are best conducted to. They are as follows:

  • Aortic Valve – R 2nd ICS
  • Pulmonary Valve – L 2nd ICS
  • Tricuspid Valve – L sternal border
  • Mitral Valve – 5th ICS MCLHeart sounds and implications of these sounds:

Normal heart sounds

Listen to Normal Heart Sounds

These consist of two sharp sounds, S1 and S2, which differentiate systole from diastole and no other significant sounds will be heard. A systole occurs when the ventricles fill with blood and the heart contracts. The sudden closure of the tricuspid valves and AV valves is caused by a decrease in pressure in the atria and a sharp increase in the intraventricular pressure which exceeds the pressure of the atria. This is the S1 sound. The ventricles continue to contract throughout systole forcing blood through the aortic and pulmonary semilunar valves. S2 is formed at the end of systole when the ventricles begin to relax and the pressure in the aorta and pulmonary artery begin to exceed the intraventricular pressure. When this happens there is a slight back-flow of blood into the heart which causes the semilunar valves to snap shut, producing S2. These two sounds are to be considered single and instantaneous, indicating a normal healthy heart.

Aortic Stenosis

This is a systolic murmur that indicates a physiological defect. The word stenosis refers to the abnormal turbulent flow of blood due to a narrow damaged blood vessel. Stenosis in the aorta results in this murmur sound which occurs between S1 and S2. In addition to this other sounds may be heard such as S4 which results from the heavy work required by the left ventricle to pump the blood though the stenotic valve. Also because S2 is caused by the sudden closing of the aortic valve ,a weaken poorly functioning stenotic valve may cause S2 to be very discreet or even inaudible. This murmur is usually best heard over the aortic area.it is important to note that this is a sharp murmur with notable start and finishing points within a systole. We can usually tell how serious the stenosis is by listening to the timing of the murmur. An early peaking murmur is usually a less serious case of stenosis , while a late peaking murmur indicates more serious stenosis, because the stenotic valve is quite weak and the ventricle takes a lot more time to build the strength to pump the blood out of the heart.

Mitral valve prolapse

This sound is thought to e caused by the failure of the papillary muscles and/or chordae to maintain tension during the late systole. As the left ventricle decreases in size the papillary muscles and/or the chordae don’t tether the valve resulting in the mitral valve remaining slightly open and a slight regurgitation period into the atium. The sound is formed during systole just when the valve prolapses and consists of a mid-systolic click just after a normal S1 sound. This sound alone is enough for diagnosis, however MVP is often followed by a murmur best heard at the apex of the heart. In addition to this ,it can be enhanced or decreased by certain manoeuvres. Standing the patient up will decrease the volume of the left ventricle and cause the MVP to occur more frequently. If the patients squats the opposite effect is seen ,the ventricle volume is increased and more tension is put on the papillary muscles and chordae which help close the valve. This condition is common in young adult women and causes symptoms of light-headedness, anxiety and palpitation attacks. Symptoms are usually mild but patients with evidence of the MVP should be given antibiotic prophylaxis when undergoing any invasive procedures to help avoid the risk of bacterial endocarditis.

Pulmonary Stenosis

This is similar to aortic stenosis in that it takes longer for the right ventricle to pump the blood out of the heart through the stenotic pulmonary valve. This results in a delay in the valve closing and causes a split in S2. This splitting of S2 is heard because the aortic valve shuts before the stenotic pulmonary valve at the end of the systole. T he splitting is best heard in the pulmonic area, the second intercostal space along the left sternal border. Maneuvers such as a heavy inspiration can increase the intensity of this murmur.

Recent Related Research (from Pubmed)

Related books from Elsevier

Click on the books to purchase with a 20% discount (add to basket and click submit for discount code)

Read 4 Credit

Would you like to earn certification to prove your knowledge on this topic?

All you need to do is pass the quiz relating to this page in the Physiopedia member area.

Go To Quiz

Find out more about a Physiopedia membership

References

  1. The Cardiac Exam: Auscultation. Available from: [ http://filer.case.edu/dck3/heart/listen.html http://filer.case.edu/dck3/heart/listen.html] [last accessed 28/5/9]
  2. Basic Heart and lung Sounds. Available from: http://www.nurse411.com/Heart_Lung_Sounds.asp [last accessed 28/5/9]
  3. Auscultation 1. Available from: http://www.youtube.com/watch?v=SBV4l3yuyDQ [last accessed 28/5/9]
  4. Auscultation 2. http://www.youtube.com/watch?v=vezboitnw6A[last accessed 28/5/9]
  5. 5.0 5.1 Auscultation Assistant. Available from: http://www.med.ucla.edu/wilkes/intro.html [last accessed 28/5/9]
  6. Respiratory Examination. Available from: http://medinfo.ufl.edu/year1/bcs/clist/resp.html [last accessed 28/5/9]
  7. 7.0 7.1 RL Wilkins, JR Dexter and JR Smith. Survey of adventitious lung sound terminology in case reports. Chest 1984, 85: 523–525.
  8. Forgacs P. The functional basis of pulmonary sounds. Chest 1978, 73(3): 399–405.
  9. ref name="Wilkins et al" /
  10. MVS Pulmonary Auscultation. Available from: http://sprojects.mmi.mcgill.ca/mvs/RESP01.HTM#abnormalsounds [last accessed 28/5/9]
  11. Shim CS, Williams MH. Relationship of wheezing to the severity of obstruction in asthma. Arch Intern Med. 1983, 143 (5): 890–2.
  12. 12.0 12.1 Baughman RP, Loudon RG. Quantitation of wheezing in acute asthma. Chest 1984, 86 (5): 718–22.
