North Star Ambulatory Assessment

Original Editor - Eki Tunjungsari Top Contributors - Eki Tunjungsari

Objective


The North Star Ambulatory Assessment (NSAA) is a 17-item rating scale that is used to measure functional motor abilities in ambulant children with Duchenne Muscular Dystrophy (DMD). It is usually used to monitor the progression of the disease and treatment effects.

Intended Population

Ambulant children with DMD.

Method of Use

Equipment Required:

  • a size-appropriate chair or height adjustable plinth
  • box step, approximately 15 cm high
  • a mat
  • a stopwatch
  • a clear, straight, and marked 10 metres pathway

Test Details and Instruction[1]:

The test must be completed without the use of any thoracic brace or leg orthoses. Therapist asks the patient to complete activities listed in the table below.

The activities are graded as follows:

2 - "Normal" - no obvious modification of activity

1 - Modified method but achieves goal independent of physical assistance from another

0 - Unable to achieve independently

This scale is ordinal with 34 as the maximum score indicating fully-independent function.

Activity Instructions to patient Starting position / test detail Comments
1. Stand Can you stand up tall for me

for as long as you can and

as still as you can?

Feet should be close together and heels on the

ground if possible. Arms by sides. NO shoes

should be worn.

Best done on the floor rather than on a mat.

Whichever is chosen maintain consistency

through repeated testing sessions. Minimum

count of 3 seconds to score 2.

2. Walk Can you walk from A to B

(state to and where from) for

me?

Walk without shoes/socks on. Should be

enough of a distance to observe ‘normal gait’

for that subject.

A value judgement needs to be made in scoring –

if the patient generally toe walks but occasionally

gets heels flat, or can on request but doesn’t

usually, they should score 1

3. Stand up

from chair

Stand up from the chair

keeping your arms folded if

you can

Starting position 90º hips and knees, feet on

floor/supported on a box step.

A size-appropriate chair or height adjustable plinth

should be used. Arms should be kept crossed

throughout the activity to score 2.

4. Stand on

one leg -

Right

Can you stand on your right

leg for as long as you can?

Minimum count of 3 seconds to score 2. NO

shoes should be worn.

Best done on the floor rather than on a mat.

Whichever is chosen maintain consistency

through repeated testing sessions.

5. Stand on

one leg -

Left

Can you stand on your left

leg for as long as you can?

Minimum count of 3 seconds to score 2. NO

shoes should be worn.

Best done on the floor rather than on a mat.

Whichever is chosen maintain consistency

through repeated testing sessions.

6. Climb

box step -

right

Can you step onto the top of

the box using your right leg

first?

Stands facing the box step. Step should be

approximately 15cm high

Support may be provided by the use of a height

adjustable plinth, or, if not available a ‘neutral’

hand from the therapist.

7. Climb

box step -

left

Can you step onto the top of

the box using your left leg

first?

Stands facing the box step. Step should be

approximately 15cm high

Support may be provided by the use of a height

adjustable plinth, or, if not available a ‘neutral’

hand from the therapist.

8. Descend

box step -

Right

Can you step down from the

box using your right leg

first?

Stands on top of the box step facing forwards.

Step should be approximately 15cm high

Support may be provided by the use of a height

adjustable plinth, or, if not available a ‘neutral’

hand from the therapist.

9. Descend

box step -

Left

Can you step down from the

box using your left leg first?

Stands on top of the box step facing forwards.

Step should be approximately 15cm high

Support may be provided by the use of a height

adjustable plinth, or, if not available a ‘neutral’

hand from the therapist.

10. Gets to

sitting

Can you get from lying to

sitting?

Starting position supine on a mat. No pillow

should be used under head

If patient turns into prone or towards the floor to

work their way into sitting 1 should be scored

11. Rise

from floor

Get up from the floor using

as little support as possible

and as fast as you can

(from supine)

Starting position supine with arms by sides,

legs straight. No pillow to be used

Activity should be attempted without use of

furniture in the first instance. Do not note time if a

chair has to be used.

12. Lifts

head

Lift your head to look at your

toes keeping your arms

folded

Supine on a mat. No pillow should be used. Ask patient to keep arms crossed over chest

during the activity to avoid self-assist. Also ask to

look at toes to ensure neck is flexed – should be a

chin to chest manoeuvre.

13. Stands

on heels

Can you stand on your

heels?

Standing on the floor. No shoes to be worn. Watch for inversion. If substantial inversion but

forefeet are still lifted – score 1. If only inversion

with lateral border of foot still on the ground score

0.

14. Jump How high can you jump? Standing on the floor, feet fairly close together. Want height, not forward movement. Small

amount of forward movement acceptable

15. Hop

right leg

Can you hop on your right

leg?

Starting position standing on floor on right leg.

No shoes should be worn.

Needs obvious floor clearance to score 2
16. Hop left

leg

Can you hop on your left

leg?

Starting position standing on floor on right leg.

No shoes should be worn.

Needs obvious floor clearance to score 2
17. Run

(10m)

Run as fast you can

to……(give point)

A straight 10m walkway should be clearly

marked in a quiet department or corridor. A

stopwatch should be used to time the walk. Be

consistent as to whether shoes are worn or not.

Ensure safety of patient. They should self

select speed after being asked to go ‘as fast as

they can’.

‘Duchenne jog’ - not a true run (there probably IS

a double support phase), but more than a walk.

Typically characterized by excessive use of arms,

trunk rotation, substantial ’waddle’. No real ‘pushoff’

Rising from floor manouver that may be presented by DMD patients.

Evidence

Several studies have shown that NSAA is a quick[2], specific[2], reliable[3][4][5], valid[3], and clinically relevant[2][3] method to measure the functional motor ability of ambulant children with DMD. NSAA is also considered to be suitable to be used in research[2] and in a multicentric setting provided that adequate training is given[4].

Reliability

  • A psychometric assessment of NSAA[3] showed that NSAA has 0.91 Person Separation Index (i.e. a reliability statistic).
  • A multicentric study[4] showed that NSAA has a high intra-observer reliability of 0.95. It has a low inter-observer reliability ( < 0.5) when assessed after only one training but the reliability increased to 0.995 after the second training. It means that NSAA is reliable in a multicentric setting provided that adequate training is given.
  • Another study[5] showed that NSAA has a high test-retest ability. It also has a high inter-rater reliability with 0.95 consistency and more than 0.93 absolute agreement.

Validity

A psychometric assessment of NSAA[3] showed that NSAA is valid with a good targeting (i.e. very few items measure the same level of ability) which equates to a better interpretation of results, This study also showed that NSAA has little misfit; which means that there was only a few items where the participants performed differently from the prediction. In fact, there was only one item (i.e. "lifting head from supine") where the participants performed significantly differently from the prediction.

Clinical Relevance

  • A psychometric assessment of NSAA[3] showed that the hierarchy of items within NSAA was supported by clinical expert opinion, thus increasing its clinical interpretability. The items in NSAA scale are listed based on their level of difficulty which is mostly agreed by experts (ρ = 0.80).
  • A questionnaire-based study[2] showed that clinicians considered NSAA as clinically relevant.

Miscellaneous

A revised version of NSAA was developed with items ordered according to the participants' age when they could be reliably performed. This version showed that NSAA can be used in patients starting from the age of three years[6].

Links

North Star Ambulatory Assessment

Registry of Outcome Measures - North Star Ambulatory Assessment

References

  1. Muscular Dystrophy UK. North Star Ambulatory Assessment. http://www.musculardystrophyuk.org/assets/0000/6388/NorthStar.pdf (accessed in 7 March 2018)
  2. 2.0 2.1 2.2 2.3 2.4 Mercuri E, Mayhew A, Muntoni F, Messina S, Straub V, Van Ommen GJ, et al. On behalf of the TREAT-NMD Neuromuscular Network. Towards harmonisation of outcome measures for DMD and SMA within TREAT-NMD; Report of three expert workshops: TREAT-NMD/ENMC workshop on outcome measures, 12th–13th May 2007, Naarden, The Netherlands; TREAT-NMD workshop on outcome measures in experimental trials for DMD, 30th June–1st July 2007, Naarden, The Netherlands; Conjoint Institute of Myology TREAT-NMD Meeting on physical activity monitoring in neuromuscular disorders, 11th July 2007, Paris, France. Neuromuscul Disord 2008;18:894–903.
  3. 3.0 3.1 3.2 3.3 3.4 3.5 Mayhew A. Cano S. Scott E. Eagle M. Bushby K. Muntoni F. On behalf of the North Star Clinical Network for Paediatric Neuromuscular Disease. Moving towards meaningful measurement: Rasch analysis of the North Star Ambulatory Assessment in Duchenne muscular dystrophy. Developmental medicine & child neurology 2011; 535-542
  4. 4.0 4.1 4.2 Mazzone ES, Messina S, Vasco G, et al. Reliability of the North Star Ambulatory Assessment in a multicentric setting. Neuromuscul Disord 2009; 19: 458–61.
  5. 5.0 5.1 Scott E. Eagle M. Mayhew A. Freeman J. Main M. Sheehan J. Manzur A. Muntoni F. Development of a functional assessment scale for ambulatory boys with Duchenne muscular dystrophy. Physiother Res Int. 2012; 17(2): 101-9
  6. Mercuri E. Coratti G. Messina S. Ricotti V. Baranello G. D’Amico A. et al. Revised North Star Ambulatory Assessment for Young Boys with Duchenne Muscular Dystrophy. PLoS ONE 2016; 11(8): e0160195. doi:10.1371/journal.pone.0160195
