Understanding active and passive insufficiency is important when assessing muscle function and optimising movement.
Active insufficiency occurs when a multi-joint muscle shortens across all joints simultaneously, reducing its ability to generate optimal tension and force.
Passive insufficiency occurs when a multi-joint muscle lengthens at all the joints it crosses. This limits the range of motion at each joint as a muscle is typically not long enough to allow full range of motion simultaneously at each joint it crosses.
Active Insufficiency
The active insufficiency of a muscle that crosses two or more joints occurs when the muscle produces simultaneous movement at all the joints it crosses and reaches such a shortened position that it no longer has the ability to develop effective tension[1]. When a prime mover (agonist) becomes shortened to the point that it cannot generate or maintain active tension, active insufficiency is reached.
The shortening of the Rectus femoris limits full hip flexion when the knee is fully extended.
Maximal shoulder flexion cannot be achieved simultaneously with maximal elbow flexion due to the shortening of the Biceps Brachii.
Maximal knee flexion and maximal plantar flexion are limited due to the shortening of the gastrocnemius.
Full knee flexion and full hip extension cannot be achieved simultaneously due to the shortening of the hamstrings.
When the opposing muscle (antagonist) is stretched to a point where it can no longer lengthen and allow further movement, passive insufficiency is reached. This limitation is a normal property of multijoint muscles and helps optimize the relation between muscle length and tension.[3] Passive insufficiency occurs when a multi-joint muscle is lengthened to its fullest extent at both joints, but also preventing the full range of motion of each joint it crosses.[4]
Image: Quadriceps passive insufficiency - Most of use would have reached our quadriceps length of passive insufficiency by now.
Full finger flexion cannot be achieved if wrist flexion occurs simultaneously.
Maximal hip flexion and maximal knee extension are limited by the lengthening of the Hamstrings.
Full knee flexion is limited by the stretching of the Rectus femoris if the hip is fully extended.
During rehabilitation, each joint should be moved individually through its available range of motion in order to optimally improve or maintain the amount of range of motion at that joint.
Practical examples
1. Addressing Active Insufficiency in Hamstrings during Knee Flexion:
Explanation: If a patient has active insufficiency in the hamstrings, limiting full knee flexion due to shortening, rehabilitation should focus on exercises that isolate and stretch the hamstrings while allowing knee flexion. For instance, seated or lying hamstring stretches with the knee flexed can help target this muscle group[6]
2. Mitigating Passive Insufficiency in the Quadriceps:
Explanation: If passive insufficiency of the quadriceps is identified, restricting full knee flexion, physiotherapists can design rehabilitation exercises that involve gradual knee flexion while avoiding simultaneous hip extension. Seated leg presses or leg curls can be suitable options[7]
3. Active Insufficiency of the Biceps Brachii:
Explanation: In cases where active insufficiency limits simultaneous maximal shoulder flexion and elbow flexion, rehabilitation exercises should focus on isolating these movements. For example, performing seated dumbbell curls can effectively target the biceps without compromising joint range[8]
4. Passive Insufficiency in Gastrocnemius during Dorsiflexion:
Explanation: Addressing passive insufficiency of the gastrocnemius during dorsiflexion involves exercises that emphasize ankle dorsiflexion while minimizing knee extension. Seated ankle stretches or dorsiflexion exercises with a flexed knee can help optimize the range of motion[9]
These practical examples demonstrate how understanding active and passive insufficiency guides the selection of exercises to target specific muscles and joints during rehabilitation. This tailored approach enhances the effectiveness of rehabilitation programs.
Case Studies
Case Study 1: Hamstring Active Insufficiency in Posterior Chain Rehabilitation:
Patient Profile:A 45-year-old male, avid runner, presented with hamstring tightness and difficulty achieving full hip flexion during running, limiting his performance and causing discomfort.
Rehabilitation Strategy: Physiotherapists identified active insufficiency in the hamstrings, restricting full hip flexion. The rehabilitation plan included targeted hamstring stretching exercises with a focus on isolated hip flexion to address the active insufficiency[10]
Case Study 2: Quadriceps Passive Insufficiency in Knee Extension:
Patient Profile: A 35-year-old female, post-knee surgery, experienced difficulty achieving full knee extension during rehabilitation exercises, limiting her ability to regain functional mobility.
Rehabilitation Strategy: Passive insufficiency of the quadriceps was identified as a limiting factor. The rehabilitation plan included exercises that gradually increased knee flexion while minimizing hip extension to optimize quadriceps function[11]
Case Study 3: Biceps Brachii Active Insufficiency in Arm Flexion:
Patient Profile: A 28-year-old male, post-shoulder surgery, faced challenges in achieving simultaneous maximal shoulder flexion and elbow flexion during daily activities, affecting his range of motion.
Rehabilitation Strategy: Active insufficiency of the biceps brachii was identified as a contributing factor. The rehabilitation plan involved isolated exercises that focused on maximizing shoulder flexion and elbow flexion independently to address the active insufficiency.[12]
These case studies demonstrate how active and passive insufficiency can be identified in clinical scenarios, leading to targeted rehabilitation strategies. Such real-world examples help bridge the gap between theoretical concepts and practical application in patient care.
References
↑Clarkson HM. Musculoskeletal assessment: joint range of motion and manual muscle strength. Lippincott Williams & Wilkins; 2000.
