Fibrodysplasia Ossificans Progressiva

Definition/Description[edit | edit source]

Dr. Victor McKusick

Fibrodysplasia Ossificans Progressiva is a rare, genetic disorder that transforms ligaments, muscles and tendons into bone outside the skeleton that impairs movement.[1] It was first described in 1692 and is characterized by progressive heterotropic ossification in anatomic structures. [2]At first it was given the name Myositis Ossificans Progressiva which means "muscle that turns to bone." [2]The name was later changed to Fibrodysplasia Ossificans Progressiva indicating "soft tissue that turns to bone." [2]The name Fibrodysplasia Ossificans Progressiva means that ligaments and tendons are also turning to bone not just muscle which differentiates it from Myositis Ossificans Progressiva.[2]This difference was discovered by Dr. Victor McKusick of Johns Hopkins University in the 1970's. [2]

Prevalence[edit | edit source]

One in every two million people are diagnosed with Fibrodysplasia Ossificans Progressiva[1]. The disease mostly begins in childhood, usually diagnosed before age ten. [2] Nearly 90% of the time the disease is misdiagnosed and mismanaged by physicians or other health care providers.[1] However, there have been 800 confirmed cases in the world and 285 in the United States.[2] 67% undergo invasive procedures for diagnosis and treatment such as, an osteotomy, blood sample, or an MRI.[1]  Fibrodysplasia Ossificans Progressiva has not been shown to be linked with any specific gender, ethnicity or race[2]

Characteristics/Clinical Presentation[edit | edit source]

  • Congenital hallux valgus with microdactyly and monophalangeal great toe are early signs that are often visible at birth.[1]
  • FOP primarily starts at the neck and shoulders then progressively moves to the trunk, back and extremities once the extra bone begins to form.[1]
  • Hallux Valgus
    Ossification of intercostal muscles[3]
  • Kyphoscoliosis and lordosis[4]
  • Severe weight loss [1]
  • Torticollis [5]
  • TMJ complications [4]

Flare-ups are usually sporadic and unpredictable. It is impossible to predict duration and severity of the flare-ups even though there has been some characteritic patterns described in some research. It is also possible that flare-ups can occur from trauma.[3]

Acute flare-ups due to: intramuscular immunizations, mandibular blocks for dental work, muscle fatigue, blunt muscle trauma from bumps, bruises, falls, influenza-like viral illnesses[3]

Prognosis[edit | edit source]

The average lifespan of these patients is approximately 40 years. Death is usually caused by respiratory infections or complications with thoracic insufficiency syndrome.[2] Most individuals with FOP are confined to a wheelchair by the second decade of life and require lifelong assistance with performing activities of daily living and more than 50% of people diagnosed with Fibrodysplasia Ossificans Progressiva will experience lifelong disabilities.[4]

Medications[edit | edit source]

There is no proven treatment or medication that will change the history of the disease for people with Fibrodysplasia Ossificans Progressiva.  Controlling progression of the disease and flare-ups are to be managed by the following:

For acute flare-ups:

  • Short term high does corticosteroids[1]
  • NSAIDS[1]
  • Biophosphonates[1]
  • Radiotherapy[1]

For chronic discomfort and ongoing flare-ups:

  • Cyclo-oxygenase-2 inhibitors[3]
  • Leukotreine inhibitors[3]
  • Mast Cell Stabilizers[3]

Diagnostic Tests/Lab Tests/Lab Values[edit | edit source]

Fibrodysplasia Ossificans Progressiva can be misdiagnosed easily, but can be avoided by examining the individual's toes for the hallux valgus and the short great toe feature, along with a thorough clinical examination and a positive test for the ACVR1 gene.[5] Genetic testing can now be done to confirm the diagnosis of FOP before the appearance of heterotropic ossification, which may avoid possible invasive treatments and diagnostic testing.[3]

Blood Samples

  • Positive for heterozygous R206H mutation of the ACVR1 gene.[1]

Computed Tomography[1]

Magnetic Resonance Imaging[1]

Bone Scans[1]

ESR elevated during acute flare-ups[1]

Etiology/Causes[edit | edit source]

  • Genetic R206H mutation of the ACVR1 gene[1]
  • ACVR1 gene is a bone morphogenetic protein (BMP) type1 receptor signaling endochondral ossification[1]
  • R206H mutation leads to an increase in enhanced BMP signaling[1]
  • Confirmation of a heterozygous gene mutation of the ACVR1 gene[1]

Systemic Involvement[edit | edit source]

Cardiopulmonary system

  • Respiratoy problems caused by thoracic insufficiencies (i.e. decreased chest wall expansion)[5]
  • Throacic Insufficieny Syndrome, a possible life-threating complication that can cause right sided heart failure and pneumonia. Maximizing pulmonary function and minimizing respiratory complications may be beneficial for these people.[3]
  • Restrictive pulmonary diseases (i.e. pneumonia)[5]

Auditory System

Ossification lower ribs
  • Middle ear ossifications[5]
  • Hearing impairments[5]

Hearing loss occurs in about half of the people diagnosed with FOP.[3]

Immune system

  • Flare-ups following viral infections can occur[5]
  • Inflammation of joints and other structures[5]

Macrophages, lymphocytes, and mast cells will be present in early lesions of fibrodysplasia ossificans progressiva.[3]

Renal system

  • Individuals with FOP are 2 times more likely to get kidney stones[3]
  • History of UTI, low fiber diet, and decreased water intake may also increase the risk of developing kidney stones in people with FOP.[3]

Integumentary system[6]

  • These individuals are at risk for pressure sores due to the decrease in soft tissue and the increase in bone.

Medical Management (current best evidence)[edit | edit source]


  • Reduces the pain and severity of flare-ups, chronic or acute

Surgical release of joint contractures[3]

  • Usually unsuccessful and may cause trauma-induced heterotrophic ossificans

Osteotomy of heterotropic bone[3]

  • Mobilizes joints
  • Usually counterproductive because new heterotrophic ossificans can form at the site

Repositioned surgically[3]

  • Improves the patients overall functional status
  • Rare

Ultimately, there is not much that can be done to cure this disease. Surgical interventions are associated with numerous complications.[3]

Clementia Pharmaceuticals Inc. is currently working on a Phase II randomized, double-blind, placebo controlled study that looks at the effect of different doses of palovarotene on bone formation during a flare up and after a flare up.  Palovarotene may prevent abnormal bone growth by disrupting the systems in the bone morphogenetic protein path, which allows for new bone formation.  The trial uses three outcomes to obtain results from the effect of the drug on people with FOP: imaging for new bone formation, assessments of function, and patient-reported outcomes.

Physical Therapy Management[edit | edit source]

Physical therapy has been shown in some cases to make the condition worse in individuals with FOP because it tends to cause flare-ups which eventually leads to further ossification of the ligaments, tendons and muscle.[2] Aquatic therapy, however has been shown to be beneficial in maintaining ROM, pain relief, and aerobic endurance.[2] Aquatic therapy provides low impact and resistance created by the water which ultimately, enhances the ease of activities of daily living, makes functional activities as easy as possible, and implements fall prevention precautions.[2]

Differential Diagnosis[edit | edit source]

Fibrodysplasia Ossificans Progressiva has been commonly misdiagnosed by physicians with the following diseases:

  • Myositis Ossficians Progressiva
  • Juvenile Fibromatosis connective tissues cells called fibroblasts that invade ligaments, tendons and muscles causing swelling.[2]
  • Lymphoedema
  • Soft tissue sarcomas/neoplasms there are many doctors that misdiagnose FOP for neoplasms due to the recurrence of soft tissue flare-ups.[2]

Case Reports/ Case Studies[edit | edit source]

  • 4 year old boy with FOP

Clinical and Genetic Analysis of Fibrodysplasia Ossificans Progressiva: A Case Report and Literature Review[1]

  • 20 year follow-up of a 23 year old female

A case of fibrodysplasia ossificans progressiva: 20 years of follow‑up[4]

  • 29 year old man with onset of sypmtoms at age 9

Fibrodysplasia ossificans progressiva without characteristic Skeletal anomalies[6]

Resources[edit | edit source]

Fibrodysplasia Ossificans Progressiva

International Fibrodysplasia Ossificans Progressiva Association

There is a support group offered to individuals diagnosed with this disorder called Internation Fibrodysplasia Ossificans Progressiva Association. It discusses the latest research, what it is like to live with FOP, and clinical trials. It was founded by Jeannie Peeper who has FOP.  She wanted to end social isolation.[2] IFOPA's "Mission of Hope"

Henry Eastlack Skeleton
Henry Eastlack was a gentlemen who suffered and died from FOP. His skeleton is now on display at The Mutter Museum of The College of Physicians in Philadelphia. When individuals die their skeleton falls apart because the connective tissue, ligaments and tendons are no longer holding their skeleton together. When a skeleton is put on display at a museum it has to meticulously be rearticulated with wires and glue. Henry's skeleton never had to be rearticulated because of the extra bone created by FOP.  His skeleton truly shows the harsh reality of FOP and the dysfunctions it can create.[2]
